Horizontal-axis flexible measurement platform for shaft-type parts, built for shop-floor production.
A horizontal-axis flexible measurement center for shaft-type parts. Dual tactile probes on a servo-driven carriage gauge diameter, form and positional tolerances in a single setup, with thermal compensation holding accuracy on the shop floor.
Horizontal layout with an enclosed work zone, status indicator and operator interface, built for installation on the shop floor.
Dual tactile probes on a servo-driven measuring carriage, with the shaft supported along its full length during gauging.
Crankshafts, camshafts, motor shafts, balancer shafts, and gearbox input and output shafts.
Diameter, roundness, cylindricity, coaxiality, runout, stroke, cam angle, and contour.
Dual-probe tactile gauging, servo auto gauging, thermal compensation, and shop-floor ready construction.
Accuracy: 1 µm + 1.5 µm per 100 mm. Resolution: 0.0001 mm.
Available in vertical or horizontal layouts.
Send us your part drawing and target cycle time and we will recommend the right configuration.
