Brake Disc Fully Automatic Balancing Machine
MRLing's fully automatic brake disc balancing machine — unbalance measurement and vertical or disc milling correction in one cycle, for workpieces up to 30kg and 300mm diameter.
The XYLD-30-4P-10 is a fully automatic balancing machine for brake discs, combining unbalance measurement with vertical or disc milling correction in a single cycle. It handles workpieces up to 30kg and 300mm in diameter, at a balancing speed of 500-800 r/min.
Unbalance is measured in 6-10 seconds and corrected by milling at a depth of 3-4mm and an arc angle of 70-90°, reducing unbalance by 90% to a residual level of 1 g·mm/kg. The machine runs on an external AC 380V supply with 0.4-0.6 MPa air; balancing motor 2.8kW, milling motor 5.5kW, total machine power 15kW. Non-standard customization is available.
Measures unbalance at 500-800 r/min, with each measurement taking 6-10 seconds.
Vertical or disc milling removes material to correct unbalance, 3-4mm deep at a 70-90° arc angle.
Reduces unbalance by 90%, achieving a residual unbalance down to 1 g·mm/kg.
Designed for brake discs up to 300mm diameter and 30kg workpiece weight.
Measurement and milling correction run in one automatic cycle without manual handling.
Configurations can be tailored to specific production requirements.
